Hardware Specifications
Sensors
Temperature specifications
Accurate with wide operating range
Accuracy at 25°C (77°F)
+/- 0.3°C (0.5°F)
Resolution
0.01°C
Time constant at 25°C (77°F)
15 sec max
Sensor weight
2.5 oz. (without probe)
Sensor dimensions
.29 in. x 1.77 in. x .66 in.
Operating temperature range
-55°C to +125°C (-67°F to +257°F)
Humidity specifications
Accurate with quick response time
Accuracy at 25°C
+3% under normal conditions (10%-90% RH)
Resolution
0.04% RH
RH operating range
0-100% RH
RH response time
8 sec (tau 63%)
Battery specifications
Long battery life of 10+ years
Battery type
2400 mAh non-chargeable battery
Battery life
Included battery will typically last 10+ years
Supply voltage
3V
Optimal battery operating temperature
-40°C to + 85°C (-40°F to +185°F)
Range specifications
Long range of 1,200 ft using LoRaWAN
Operating frequency
900 MHz (US, configurable for other countries)
Certifications
Complies with Part 15 of FCC Rules (FCC ID ZHZLHT65)
Device range
Up to 1,200 ft non-line of site
Security
AES-128 CBC with Diffie-Hellman Key Exchange
4G Cellular Hub
Cellular specifications
Multi-carrier SIM included
Cellular technology
4GLTE
SIM card
Hologram (multi-carrier: Verizon, T-Mobile, At&T)
SIM card compatibility
Micro-SIM (3FF) 15 mm x 12 mm x 0.76 mm
Device memory
50,000 sensor messages. Sensor messages will be stored in the event of Internet outage and transferred when connection is restored
Physical specifications
Small and lightweight for hard-to-reach places
Hub weight
5.29 oz.
Hub Dimensions
4.72 in. x 3.34 in. x 1.18 in.
LED Lights
Internet connectivity status, power status, sensor network status
Operating temperature
+5 to 45°C (41 to 113°F)
Range specifications
Long range of 1,200 ft using LoRaWAN
Operating frequency
900 MHz (US, configurable for other countries)
Certifications
Complies with Part 15 of FCC Rules (FCC ID: ZHZHE)
Device range
Up to 1,200 ft non-line of site
Security
AES-128 CBC with Diffie-Hellman Key Exchange
